Separate Crystal Lens 660nm Red Line Laser Module

Qualified separate crystal lens 660nm red line laser module assures the most special and uniform distribution red laser beam emission, and up to 85% uniformity red line alignment. Equipping with cooling system and APC, ACC driving circuit board inside durable aircraft used aluminum alloy housing tube, it achieves the best quality red laser light source emission, and the finest and brightest red reference line indication for both industrial and high line aligning fields.

Regular Price $108.99 Special Price $87.99
Availability: In stock
SKU
660-SCRLLM
  • Buy 3 for $85.99 each and save 2%
  • Buy 5 for $83.99 each and save 5%
  • Buy 10 for $81.99 each and save 7%

The most reliable and precise red laser line alignment solution with low production cost.
Employing import 660nm red laser diode and qualified separate crystal lens, 660nm red line laser module is performing with the best quality red laser light source emission, and high fineness red line projection from beam aperture. Configured with metal heat sink cooling system inside compact size metal housing tube, red laser line generator enables easy installation, quick response and low cost red line aligning source for a lot of application fields, including lab, institute, prominent universities etc.

◆ Adjustable focus optic lens gets increasing accuracy line alignment. 635nm red line laser module gets immediate red laser light concentration, converting into a highly fine and bright red line alignment in distance.

◆ Wide range output power of 5mW to 100mW enables clear line alignment in multiple applications. Employing import 660nm red laser diode and metal heat sink cooling system inside aircraft used aluminum alloy housing tube, it achieves increasing beam stability and highly clear line alignment within maximum distance of 25 meters.

◆ Separate crystal lens assures the most precise red line emission. Within 10 degree to 93 degree fan angles, 660nm red line laser module assures non Gaussian distribution red laser beam and highly uniform red line. It makes no mistake and no decay light line alignment in constant use.

◆ AC/DC adapter assures continuous line alignment. Selecting 5V, 9V 1000mA DC power supply, red laser line alignment keeps stable performance under increasing temperature and up to 85% beam stability within 8 to 10 hours use.

Technical Parameter:

Item Separate Crystal Lens Red Line Laser Module
Wavelength (nm) 660nm
Output power (mW) 5mW-100mW
Available Fan Angle (degree) 16°- 93°
Beam diameter at aperture (mm) <2.0mm; at 2m diameter: <2.0mm
Beam divergence (mrad) 5 mrad
Beam mode TE
Focus adjustable? Yes
Operating voltage(v)  5mW-20mW:DC=5V; 30mW-100mW:DC=9V
Operating current (mA)  I<1000mA
Operating temperature(℃) 10℃~45℃
Storage temperature(℃) -10℃~50℃
Dimension  5mW-20mW: D16mm×L71mm;30mW-100mW: D26mm×L150mm
Expected lifetime (hours) ≥8000 hours
Warranty 6 months

Packing list: 1 pc Separate crystal lens 660nm red line laser module and 1 pc AC/DC adapter

Applications: textile garment processing, laser cutting machine, embroidery machine, stone, wood, metal processing

Note: High power separate crystal lens 660nm red line laser module up to 50mW to 100mW emits powerful red laser light and seriously thermal energy hurt to human eyes. Do remember to avoid any eye exposure to beam aperture, and wear 660nm wavelength preventing laser safety goggles for all constant red line alignment works.
