635nm Red Laser Diode Module

Be the first to review this product

Payment Option:

Availability: In stock

Regular Price: $90.98

Special Price $78.99

  • Buy 2 for $76.98 each and save 3%
  • Buy 5 for $73.98 each and save 7%
  • Buy 10 for $69.98 each and save 12%

Quick Overview

635nm red laser module adopts compact version design with proper qualified 635nm red laser diode, optics, constant current electric circuit board, and durable housing. It is projecting 3 times brighter red laser beam than common 650nm red laser, offering ideal laser source for extremely bright and visible beam required fields. This laser diode module makes great job of higher stability, lower power consumption, less heat generation, and longer serving lifetime.

* Required Fields

Details

635nm red laser diode module manufactured from Berlinlasers integrates quality laser diode, perfect optics and durable package, providing high stability red laser source for wide application of industrial alignment, military targeting, lab experiment, medical etc.

Adjustable focus lens assures easy targeting. This red laser module allows easy adjustment of beam focus to obtain various diameter laser sources on various working surfaces. CW modulation with optimized thermal stabilization assures continuous laser source supplying with perfect beam collimation and alignment.

Compact structure laser module with high stability power emitting. With wide output power range level of 5mW to 100mW, 635nm red laser diode modules are available with compact version of 16mm and 26mm diameters. Internal constant current driving circuit board and thermal control system get high power stability of better than 5% over 8 hours.

Good performance in all working conditions. Housing part utilizes aircraft used aluminum with anodized treatment, giving 35nm red laser module perfect electrical isolation, and laser module is perfectly protected from mechanical shock, vibration and thermal conductive.

Technical Data:

Item Red Laser Diode Module
Wavelength (nm) 635nm
Output power (mW) 5mW, 10mW, 20mW, 30mW, 50mW, 80mW,100mW
Laser Class IIIa, IIIb
Beam thickness at aperture (mm) <2mm
Beam divergence (mrad) <2mrad
Beam mode (before optics) TEM00
Focus adjustable? Yes
TTL Modulation NO
Operating voltage(v)  5mW-30mW:DC=3.0V; 50mW-100mW:DC=4.2V
Operating current (mA)  5mW-30mW: I<500mA; 50mW-100mW: I<1000mA
Operating temperature(℃) 10℃~30℃
Storage temperature(℃) -10℃~50℃
Dimension  5mW-30mW: D16mm×L71mm;50mW-100mW: D26mm×L150mm
Expected lifetime (hours) 8000 hours
Warranty Period 180 days

Power Supply:

Input: AC 100-240V, 1.0A , 50/60Hz
Output: DC 3V ,500mA
Dimension: 70mm×46mm×27mm
Length of AC input line: 116cm
Length of DC output line: 126cm

Packing List:
1. Red laser diode module
2. DC input power Supply optional

Attention: For high powered or OEM 635nm red laser diode module, please contact us free at support@berlinlasers.com.
