1470nm 100mW 200mW 300mW 500mW 1000mW Infrared Cross Line Laser Modules
Intense invisible beam 1470nm infrared cross line laser modules adopt import 1470nm infrared laser diode, qualified glass coated lens and APC, ACC driving circuit board, project high intensity infrared laser light and highly clear infrared vertical and horizontal cross line source in distance. Equipping with night version device and electric power source, it assures high stability, good collimation and competitive price infrared cross line measurement for night version fields.
- Buy 3 for $297.99 each and save 1%
- Buy 5 for $295.99 each and save 1%
- Buy 10 for $293.99 each and save 2%
Continuous wavelength 1470nm infrared cross line laser modules get featured advantages of ultra compact design, easy installation and quick response. Available with wide ran angles glass coated lens and glass window, after up to 24 hours beam stability tests, the genuine infrared cross line alignment keeps stable and reliable performance for long lasting and long distance use.
Key features:
Import 1470nm 100mW to 1000mW infrared laser diode with metal heat sink and APC, ACC driving circuit board inside 16mm or 26mm diameter metal housing tube, achieves good thermal emitting, up to 85% beam stability and long operating lifetime.
AC/DC adapter supported 1470nm infrared lasers achieve constant infrared laser beam and infrared cross line projection, no effect of overheating and over current impact.
Wide fan angles 10, 15 and 110 degree glass coated lens generates high linear quality and highly straight infrared cross line source, applying for multiple application fields.
Adjustable focus optic lens makes high concentration infrared laser light, and converts into highly precise and fine infrared cross line alignment in distance
CW or pulsing laser selectable
Technical data:
| Item | Infrared Cross Line Laser Modules |
| Wavelength(nm) | 1470nm |
| Output power(mW) | 100mW 200mW 300mW 400mW, 500mW 1000mW |
| Available Fan Angel (degrees) | 10°,15°,110° |
| Beam diameter at aperture(mm) | <2.5mm |
| Beam divergence(mrad) | 6 mrad |
| Beam mode | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L71mm; D26mm×L150mm |
| Expected lifetime (hours) | ≥8,000 hours |
| Warranty | 6 months |
Packing list: 1 ea 1470nm infrared cross line laser module and 1 ea AC/DC adapter
Applications: infrared cross measurement, laser communication, spectrum analysis, scientific experiment etc
Note: Human eyes cannot capture any invisible infrared laser radiation and reflection. Please avoid eye exposure to beam aperture. Do remember to wear laser safety goggles so as to make free and secured cross line measurement constantly.
