445nm Blue Parallel Line Laser Module

Among all visible lasers, 445nm blue parallel line laser module gets extremely bright and charming blue color laser light, fulfilling high level of accuracy and precision parallel alignment result under high lighting and long distance parallel laser alignment in industrial laser use fields. Integrated all parts of import 445nm blue laser diode, qualified glass cylindrical lens, electric driving circuit and metal heat sink cooling system into quite compact anodized aluminum housing, this industrial blue parallel laser alignment allows easy and convenient operation for all industrial parallel alignment and configuration efficiently.

was $589.99 Special Price $559.98
Availability: In stock
SKU
445BPLLM
  • Buy 3 for $556.99 each and save 1%
  • Buy 5 for $553.98 each and save 1%
  • Buy 10 for $550.98 each and save 2%

445nm blue parallel line laser module gets direct parallel line laser source emission from 445nm blue laser diode, together with enough space reserved as its thermal stabilization system, ensuring the most stable and reliable blue parallel line beam emission in 24 hours continuous operation. According to wide selection of output power range from 50mW to 100mW, parallel line laser gets 12m, 16mm, 26mm and 38mm diameter anodized aluminum housing, allows easy selection for getting ideal parallel alignment result as expected. High transmittance 445nm blue parallel laser alignment gets multiple pattern, 5 parallel lines, 25 parallel lines, and customized parallel laser acceptable.

Key features:

Anodized aluminum housing tube with multiple size: 12mm*75mm, 16mm*75mm, 38mm*160mm
Metal heat sink cooling system together with metal housing ensures perfect thermal conductivity, making good parallel line alignment result under wide operation temperature of -10 degree to 50 degree Celsius.
Qualified glass cylindrical lens enables at least 80% laser beam transmittance. 445nm blue parallel line laser source keeps extremely bright and visible under all work fields.
Adjustable focus designed 445nm blue parallel line laser module allows free adjustment of laser beam focus, increasing parallel line alignment accuracy and precision exactly.
Rapid parallel line laser targeting, low time consumption and low power consumption.
Stable and reliable parallel alignment, up 8,000 hours serving lifetime.

Technical Data:

Item Parallel Line Laser Module
Wavelength 445nm
Projection Type 25 parallel lines, 5 parallel lines
Output power 50mW, 80mW, 100mW
Laser Safety Class Class IIIb
Fan angle 0.02mrad
Beam Diameter at Aperture 8mm, 20mm
Laser Dimension 12mm*75mm, 16mm*75mm, 38mm*160mm
Laser Power Supply DC5 V, DC12V, DC24, AC90-220V
Serving lifetime more than 8,000 hours
Warranty Period 180 Days

Application:

445nm direct diode emission blue parallel line laser module gets wide applications in long distance tunnel through positioning, bridge cranes, paper mills, roller and web handing system, steel mills, aligning tracks and guide rails, material handing rail cart systems, alignment sprocket and drive system, and many other special occasions.
445nm blue parallel line laser is also a monochromatic light source, available with high degree of parallelism for industrial version and other industrial automation perspective, teaching experiments etc.
