Uniform Distribution 660nm Red Laser Line Generator

Employing the best quality import 660nm red laser diode and qualified separate crystal lens into durable aircraft used aluminum alloy housing tube, forming into an industrial stabilized 660nm red laser line generator. This direction diode emission 660nm red laser module gets good thermal emitting and constant power source supply, fulfilling the most reliable and the most accurate red line alignment for a lot of application fields, including institutes, labs, and universities.

was $109.99 Special Price $88.98
Availability: In stock
  • Buy 3 for $86.98 each and save 2%
  • Buy 5 for $84.98 each and save 4%
  • Buy 10 for $82.98 each and save 7%

Formal brightness 660nm red laser line laser enables the finest and the lowest price line alignment.
The best quality separate crystal lens made 660nm red laser line generator enables uniform distribution red laser beam emission and highly uniform red reference line projection. Configured with good thermal emitting system and APC, ACC driving circuit board, this 660nm red laser module gets the best red laser light source, and the most reliable red line aligning solution for modern time industrial laser line alignment, high tech and scientific research works.

Import 660nm red laser diode assures highly stable line alignment. AC/DC adapter equipped 660nm red laser module within 5mW to 100mW assures continuous red laser beam emission and highly clear red line alignment. The genuine line indication gets no light decay or blur.

Qualified separate crystal lens assures the best line aligning source in distance. Available with 10° to 93°fan angles, 660nm red laser line generator projects highly uniform and the same brightness red line emission within 0.5 meter to 6 meters. Adjustable focus optic lens assures no mistake and no labor force input line alignment perfectly.

APC, ACC driving circuit enables reliable line alignment constantly. The genuine red laser line alignment gets no affects by increasing temperature and serious electric current impact. 660nm red laser module gets up to 85% beam stability within 8 to 10 hours, and up to 8,000 hours lifetime.

Technical Parameter:

Item Uniform Distribution Red Laser Line Generator
Wavelength (nm) 660nm
Output power (mW) 5mW-100mW
Available Fan Angle (degree) 16°- 93°
Beam diameter at aperture (mm) <2.0mm; at 2m diameter: <2.0mm
Beam divergence (mrad) 5 mrad
Beam mode TE
Focus adjustable? Yes
Operating voltage(v)  5mW-20mW:DC=5V; 30mW-100mW:DC=9V
Operating current (mA)  I<1000mA
Operating temperature(℃) 10℃~45℃
Storage temperature(℃) -10℃~50℃
Dimension  5mW-20mW: D16mm×L71mm;30mW-100mW: D26mm×L150mm
Expected lifetime (hours) ≥8000 hours
Warranty 6 months

Packing list: 1 pc uniform distribution 660nm red laser line generator and 1 pc AC/DC adapter

Applications: laser cutting machine, sand milling, lumber machine, textile garment processing, stone, wood, metal processing etc

Note: The genuine use of high power uniform distribution 660nm red laser line generator allows generates powerful red laser light and thermal energy from beam aperture. It might cause seriously hurt to human eyes.
Do avoid any eye exposure to laser beam aperture, and wear proper 660nm wavelength preventing laser safety goggles to achieves free and safe line alignment constantly.
