1064nm 100mW to 500mW Infrared Laser Line Generators
Long wavelength 1064nm infrared laser line generators allow operation with night version device and external electric power source. Being made with import 1064nm infrared laser diode, qualified optic lens, electric driving circuit board, it gets good industrial stabilization, thermal emitting and highly reliable infrared laser light and infrared reference line generation for all night version illumination fields.
- Buy 3 for $207.99 each and save 1%
- Buy 5 for $205.99 each and save 2%
- Buy 10 for $203.99 each and save 3%
Direct diode emission 1064nm infrared laser line generator gets featured advantages of ultra compact and durable structure, high beam stability, low production cost and good direction. Employing by anodized aluminum alloy housing tube with 16mm and 26mm diameter, 940nm infrared laser module enables convenient installation, quick and no barrier infrared line alignment.
Key features:
1064nm 100mW to 500mW infrared laser modules with metal heat sink and APC, ACC driving circuit assure good thermal emitting and increasing stable beam stability.
5V, 9V 1000mA AC/DC adapter leaves larger space for tube cooling down, keeps highly stable infrared line alignment, and no effect of overheating or over current.
10-110 Degree fan angles glass coated lens or Powell lens generates high linear quality and various lengths infrared laser line for multiple precise line measurements.
Adjustable focus lens gets high concentration infrared laser light of beam aperture, efficient conversion of highly fine line source at great distance.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Laser Line Generators |
| Wavelength (nm) | 1064nm |
| Output power (mW) | 50mW,100mW, 200mW, 300mW, 400mW, 500mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIB, IV |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 1064nm infrared laser line generator and 1 ea AC/DC adapter
Applications: laser collimation, laser medical surgery, scientific experiment, infrared laser communication and optical instruments
Note: The operation of 1064nm infrared laser module projects invisible and powerful infrared laser radiation and reflection. It might cause potential thermal energy hurt to human eyes. Please remember to wear correct laser safety goggles and avoid eye exposure to beam aperture so as to gets secured and fine use constantly.
