1064nm 50mW to 500mW Infrared Line Laser Modules
High intensity beam 1064nm infrared line laser module adopts import 1064nm infrared laser diode, qualified optic lens and APC, ACC driving circuit board, generates high photoelectric ability infrared laser light emission at long distance. Only after professional equipment with night version device and external electric power source, it assures efficient conversion of the clearest and the most stable line measurement.
- Buy 3 for $367.99 each and save 1%
- Buy 5 for $364.99 each and save 1%
- Buy 10 for $361.99 each and save 2%
Long wavelength 1064nm 100mW to 500mW infrared line laser modules only allow easy use after configuration with night version devices. Designed with qualified glass coated lens or Powell lens, and strict beam stability test up to 24 hours and special use of a glass widow, it makes perfect protection of itself, and provides the most reliable infrared line alignment for multiple night version fields.
Import 1064nm infrared laser diode with metal heat sink cooling system and APC, ACC driving circuit board inside 16mm or 26mm diameter metal tube assure good thermal emitting, high beam stability within 8 to 10 hours use.
5V, 9V 1000mA AC/DC adapter assures constant infrared laser beam and infrared line alignment, no effect of overheating and over current impact as well.
Wide fan angles of 10 to 110 degree glass coated lens or Powell lens generates various lengths and high linear quality infrared line projection, fulfills multiple precise line measurement fields.
Adjustable focus optic lens gets high concentration infrared laser light emission, increasing accuracy and fineness infrared line alignment in distance.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Line Laser Modules |
| Wavelength (nm) | 1064nm |
| Output power (mW) | 50mW,100mW, 200mW, 300mW, 400mW, 500mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIB, IV |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 1064nm infrared line laser module and 1 ea AC/DC adapter
Applications: collimation, laser medical surgery, lab experiment, infrared laser sight, optical instrument and high tech
Note: Any operation of invisible beam 1064nm infrared laser projects powerful infrared laser radiation and reflection. In order to avoid thermal energy hurt to eyes, please remember to wear laser safety goggles and avoid eye exposure so as to make free and easy measurement perfectly.
