488nm 5mW to 100mW Blue Line Laser Modules
High brightness 488nm blue line laser module applies import 488nm blue laser diode, qualified optic lens and APC, ACC driving circuit board, projecting intense blue laser light, and highly clear and reliable blue reference line from beam aperture. Under operation with correct output power and fan angles, and proper equipment with industrial machine or device, industrial stabilized blue laser assure low production cost, good stability and long lasting line measurement for industrial and high tech fields.
- Buy 3 for $177.99 each and save 1%
- Buy 5 for $175.99 each and save 2%
- Buy 10 for $173.99 each and save 3%
Durable structure 488nm blue line laser modules get featured advantages of ultra compact design, good direction, and quick response. Equipping with external electric power source and easy screw of adjustable focus lens, it gets constant blue laser light emission, and increasing accuracy and brightness blue line alignment at various work distances.
Key features:
Configuring 488nm blue laser diode within 5mW to 100mW and metal heat sink cooling system with anodized aluminum alloy housing tube, blue laser module assures superior nice thermal emitting and increasing stability blue line projection.
AC/DC adapter with 5V, 9V operating voltage assures constant and intense blue laser light emission. Within freely installed distance of 3 meters, blue laser line makes no barrier and noncontact measurement, no affect by overheating and over current.
Qualified glass coated lens and Powell lens within 10-110°assrues high quality Gaussian or Non Gaussian distribution blue laser beam emission. High linear quality and high fineness blue laser line assures maximum work distance of 25 meters.
Adjustable focus optic lens allows freely adjusted blue line fineness, increasing accuracy and brightness line measurement in use.
CW or pulsing laser selectable
Technical data:
| Item | Blue Line Laser Modules |
| Wavelength (nm) | 488nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2.5mm; At 2m distance: <2.5mm |
| Beam divergence (mrad) | 1.5mrad |
| Beam mode (before optics) | near TEM00 |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 488nm blue line laser module and 1 ea AC/DC adapter
Applications: laser medical imaging, biomedical, high tech, laser show, laser displaying and industrial precise line alignment
Note: The use of 488nm blue laser up to 50mW to 100mW generates seriously intense and powerful blue laser light and thermal energy. In order to get secured and free line alignment, please remember to wear correct laser safety goggles and avoiding eye exposure to beam aperture.
