905nm 5mW to 500mW Infrared Laser Line Generators
Invisible beam 905nm infrared laser line generator enables easy and convenient line alignment as an accessory part. Equipping with night version device and external electric power source, within wide range output power of 5mW to 500mW, it assures high intensity infrared laser light emission, and efficient conversion of high precision and high fineness infrared line measurement for all night version labs, institutes and scientific research etc.
- Buy 3 for $117.99 each and save 2%
- Buy 5 for $115.99 each and save 3%
- Buy 10 for $113.99 each and save 5%
Long wavelength 905nm infrared laser line generator provides the most professional infrared line aligning solutions for all night version applications. Ultra compact anodized alloy housing tube made device enables easy installation, quick response, good direction and low production cost. After easy adjustment of both laser beam focus and infrared line direction, 905nm infrared laser module assures increasing accuracy and brightness infrared line measurement.
Key features:
Import 905nm infrared laser diode within 5mW to 500mW inside durable metal housing tube assures increasing beam stability and highly clear infrared line alignment at various work distances.
5V, 9V 1000mA AC/DC adapter supported 905nm infrared laser modules make constant infrared laser beam and infrared line emission stably, without effect of overheating or over current impact.
Wide fan angles of 10 to 110°glass coated lens or Powell lens enables high photoelectric infrared laser light emission and high linear quality infrared line projection with various line lengths.
Ultra compact 16mm or 26mm diameter metal housing tube assures convenient installation within 3 meters, no barrier and no mistake infrared line measurement in long time use.
CW or Pulsing laser selectable
Technical data:
| Item | Infrared Laser Line Generators |
| Wavelength (nm) | 905nm |
| Output power (mW) | 5mW50mW, 100mW, 200mW, 300mW, 400mW, 500mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIB, IV |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 905nm infrared laser line generator and 1 ea AC/DC adapter
Applications: spectrum analysis, precise infrared line alignment, infrared laser sight, laser medical therapy, lab experiment etc
