Adjustable Focus 455nm 5mW to 100mW Blue Laser Line Generators
Industrial stabilized 455nm blue laser line generators make advanced use import 455nm blue laser diode, qualified glass coated lens or Powell lens, and APC, ACC driving circuit board. It provides users the most reliable blue laser light source, and highly clear and fine blue reference line generation. Correct selection of output power and optic lens fan angle ensure no labor force and no mistake line alignment for both industrial and high tech precise line measurements.
- Buy 3 for $126.99 each and save 2%
- Buy 5 for $124.99 each and save 3%
- Buy 10 for $122.99 each and save 5%
Direct diode emission 455nm blue laser line generators get featured advantages of ultra compact design, easy operation, high precision and low production cost. 16mm or 26mm diameter anodized aluminum alloy housing tube device enables convenient installation, quick response and good direction blue line alignment.
Key features:
Import 455nm blue laser diode within 5mW to 100mW made blue laser modules assure highly visible blue laser beam emission and increasing stability blue line generation in constant use.
AC/DC adapter supports 455nm blue laser with continuous blue laser light emission. The real blue laser line alignment keeps stable and clear line alignment, no affect by increasing temperature and serious electric current impact.
High durable anodized aluminum alloy housing material assures wide range operating temperature stabilization, good thermal conductivity, and stable blue line alignment under moving or calibration.
Wide fan angles Glass coated lens and Powell lens within 10 to 110 degree fulfills high precision and high fineness blue line alignment under multiple application fields.
Adjustable focus lens enables freely adjusted blue line fineness, and the finest blue line alignment in distance.
CW and pulsing laser selectable
Technical data:
| Item | Blue Laser Line Generators |
| Wavelength (nm) | 455nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 20°, 30°, 45°, 50mW, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2.5mm; At 2m distance: <2.5mm |
| Beam divergence (mrad) | 3.0mrad |
| Beam mode (before optics) | TEM |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 455nm blue laser line generator and 1 ea AC/DC adapter
Applications: laser show, laser displaying, spectrum analysis, industrial line alignment, scientific research and high tech etc
Note: For operation of high power 455nm blue line laser module up to 50mW to 100mW, powerful blue laser radiation and thermal energy might cause hurt to human eyes and retina. Do remember to wear correct laser safety goggles and avoid eye exposure to beam aperture so as to assure free and secured blue line alignment constantly.
