Direct Diode 455nm 5mW to 100mW Blue Line Laser Modules
Direct diode emission 455nm blue line laser modules get featured advantages of ultra compact structure, easy operation, good direction and high precision blue line measurement. Integrating qualified optic lens, import 455nm blue laser diode, and thermal emitting system with durable metal housing tube, this 455nm blue laser module gets superior nice beam stability, and highly clear and accurate blue line alignment for both industrial and high tech precise line measuring fields.
- Buy 3 for $127.99 each and save 2%
- Buy 5 for $125.99 each and save 3%
- Buy 10 for $123.99 each and save 5%
Industrial stabilized 455nm blue line laser modules gets basic use of cooling system, APC, ACC driving circuit board, providing users the most reliable blue laser light source and highly clear blue reference line projection in continuous use. After connecting with external electric power source and special use of adjustable focus optic lens, it provides users increasing accuracy and brightness blue line measurement at various work distances.
Key features:
Configured with import 455nm blue laser diode within 5mW to 100mW and metal heat sink cooling system, 455nm blue laser line generator gets 40% improvement of laser beam stability and long lasting blue line projection.
AC/DC adapter with 5V, 9V operating voltage assures continuous blue laser beam and blue line generation. Within maximum 3 meters installed distance, blue laser line measurement makes no barrier and no mistake use.
Adjustable focus optic lens allows immediate blue light concentration, converts into the most precise blue line alignment.
Quality glass coated lens and Powell lens within 10 to 110 degree fan angles assure high intensity blue laser light emission, highly fine line measurement for multiple application fields.
APC, ACC driving circuit board makes intelligent feedback control of output power and electric current supply. Blue laser line alignment gets reduced tube burning out or damage, and no light decay.
Technical data:
| Item | Blue Line Laser Module |
| Wavelength (nm) | 455nm |
| Output power (mW) | 5mW, 10mW, 20mW, 30mW, 50mW, 80mW, 100mW |
| Available Fan Angle(degrees) | 10°, 20°, 30°, 45°, 50mW, 60°, 93°,110° |
| Laser Class | IIIa, IIIB |
| Beam thickness at aperture (mm) | <2.5mm; At 2m distance: <2.5mm |
| Beam divergence (mrad) | 3.0mrad |
| Beam mode (before optics) | TEM |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 455nm blue line laser module and 1 AC/DC adapter
Applications: laser communication, laser show, laser displaying, scientific research, measurement, spectrum analysis
Note: After the use of high power 455nm blue line laser module up to 50mW to 100mW, it projects powerful blue laser light and thermal energy. It might cause hurt to human eyes and retina. Please avoid eye exposure to beam aperture and wear laser safety goggles and glasses so as to assure easy and free blue laser line alignment constantly.
