Night Version 940nm 100mW to 500mW Infrared Laser Line Generators
Direct diode emission 940nm infrared laser line generators apply import 940nm infrared laser diodes, qualified optic lens, and electric driving circuit board, forming into a professional night version applied line measurement device. After proper equipment with night version device and electric power source, 940nm infrared laser modules assure constant infrared laser light and infrared reference line generation for all labs, institutes and colleges.
- Buy 3 for $117.99 each and save 2%
- Buy 5 for $115.99 each and save 3%
- Buy 10 for $113.99 each and save 5%
High photoelectric ability and high intensity beam emitting tool of 940nm infrared laser line generators makes advanced use of qualified glass coated lens or Powell lens with wide fan angles, and special designed glass window, it gets good operating temperature stabilization, and no decay light infrared line alignment for multiple occasions. Up to 24 hours aging preventing and beam stability tests just assure high stability, low price and good direction line alignment constantly.
Key features:
Import 940nm infrared laser diode within 100mW to 500mW with metal heat sink cooling system assures excellent thermal emitting, and 40% improvement of laser beam stability.
Wide fan angles 10 to 110 degree glass coated lens or Powell lens made infrared laser modules project high quality Gaussian beam or uniform distribution infrared laser light emission, and high fineness infrared line projection with various line lengths.
AC/DC adapter accepts wide electric current of 100V to 240V, apply for continuous infrared laser beam and infrared line projection within 8 to 10 hours, no effect of overheating and over current impact.
Adjustable focus optic lens enables high concentration infrared laser light of beam aperture, converts into high fineness and high fineness infrared line alignment under all night version fields.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Laser Line Generators |
| Wavelength (nm) | 940nm |
| Output power (mW) | 100mW, 200mW, 300mW, 400mW, 500mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIB, IV |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 940nm infrared laser line generator and 1 ea AC/DC adapter
Applications: laser medical surgery, measurement, laser communication, scientific research, spectrum analysis and lab experiment work etc
Note: Any output power 940nm infrared laser module projects invisible and super powerful infrared laser radiation and reflection. Please avoid eye exposure to beam and wear laser safety goggles or glasses so as to assure secured and fine line alignment.
