940nm 100mW-500mW Infrared Line Laser Modules
Intense infrared laser light emitting tool of 940nm infrared line laser module adopts import 940nm infrared laser diode, qualified optic lens and electric driving circuit board, projecting high intensity and high photoelectric ability infrared laser light of beam aperture. Connecting with professional night version device and external electric power source, it makes constant and high stability infrared line measurement for all labs, institutes and high tech application fields.
- Buy 3 for $117.99 each and save 2%
- Buy 5 for $115.99 each and save 3%
- Buy 10 for $113.99 each and save 5%
High durable anodized alloy housing made 940nm infrared line laser modules get featured advantages of ultra compact structure, good direction, low production cost and quick response. Cooperating with qualified glass coated lens or Powell lens, it generates the best quality Gaussian or uniform distribution infrared laser light, and the most reliable and the clearest infrared line source for night version measurements.
Key features:
Wide output power of 100mW to 500mW 940nm infrared line laser modules with metal heat sink and APC, ACC driving circuit boards assure the best beam stability, and clear and no blur beam infrared line projection within 8 to 10 hours.
Wide fan angles of 10 to 110 degree glass coated lens or Powell lens with up to 24 hours aging preventing test assure intense and high transmittance infrared laser light, different lengths infrared lines for multiple applications.
5V, 9V 1000mA AC/DC adapter keeps work with constant infrared laser beam emission, without effect of overheating and over current impact.
Freely adjusted laser beam focus allows high concentration infrared laser light emission, increasing brightness and fineness infrared line alignment in distance.
CW or pulsing laser selectable
Technical data:
| Item | Infrared Line Laser Modules |
| Wavelength (nm) | 940nm |
| Output power (mW) | 100mW, 200mW, 300mW, 400mW, 500mW |
| Available Fan Angle(degrees) | 10°, 16°, 20°, 30°, 45°, 50°, 60°, 93°,110° |
| Laser Class | IIIB, IV |
| Beam thickness at aperture (mm) | 10cm distance:<2.5mm |
| Beam divergence (mrad) | 6mrad |
| Beam mode (before optics) | TE |
| Focus adjustable? | Yes |
| Operating voltage(v) | DC＝5V, 9V |
| Operating current (mA) | I<1000mA |
| Operating temperature(℃) | 10℃～45℃ |
| Storage temperature(℃) | -10℃～50℃ |
| Dimension | D16mm×L91mm;D26mm×L150mm |
| Expected lifetime (hours) | 8000 hours |
| Warranty Period | 180 days |
Packing list: 1 ea 940nm infrared line laser module and 1 ea AC/DC adapter
Applications: laser medical treatment device, infrared laser communication, spectrum analysis, lab experiment and experiment etc
Note: For operation of invisible beam emitting 940nm infrared lasers, human eyes cannot capture any powerful IR laser radiation and reflection. Do be careful with potential thermal energy hurt, and wear correct laser safety goggles so as to assure safe and free line alignment.
